Automotive radar uses communication technologies such as Short Range Devices (SRD) that operate within a specific frequency spectrum. This technology must meet the main requirements through a standard testing process to ensure its quality, security, and compliance with applicable regulations.
This standard automotive radar testing process is stated in the Ministerial Decree of the Ministry of Communication and Digital No. 260 of 2024 which regulates various technical aspects, ranging from radio frequency, and transmit power, to testing methods.
SRD technology, which is widely used in automotive radar devices must comply with this standard to be used legally in Indonesia.
Also Read
Table of Contents
New Regulations on Automotive Radar Technology
Ministerial Decree of the Ministry of Communication and Digital No. 260 of 2024 sets technical standards that must be met by automotive radar devices to be used legally in Indonesia.
This regulation covers radio frequency requirements, maximum transmit power, and testing for wild emissions (spurious emissions).
The following are the standard specifications:
| Radio Frequency Band | Field strength / RF output power | Transmitter Spurious Emission | Testing Method | Other Condition |
| 24 – 24.25 GHz | ≤ 20 dBm EIRP | EN 302 858 | EN 302 858 | – |
| 76 -77 GHz | ≤ 55 dBm EIRP | EN 301 091-1 | EN 301 091-1 and/or EN 303 396 | – |
| FCC Part 95.3379 | FCC Part 95M And ANSI C63.26 / ANSI C63.10 |
Automotive Radar Testing Standards
Ministerial Decree of the Ministry of Communication and Digital No. 260 of 2024 refers to international standards-based test methods such as FCC, EN, and ANSI. Here are some of the main testing methods:
- Transmit power testing (RF output power): Ensure the device does not exceed the maximum transmit power limit according to its frequency band.
- Spurious emission testing: Tests stray frequency emissions outside the working band to prevent interference with other devices.
Electromagnetic Compatibility (EMC) Testing: Assesses the device’s compatibility with the surrounding electromagnetic environment to avoid interference.
Additional technical requirements
Apart from testing transmittance and emissions, the Ministerial Decree of the Ministry of Communication and Digital No. 260 of 2024 also regulates several other technical requirements, including:
- Electrical safety: The device must comply with the electrical safety standards set out in SNI IEC 60950-1:2016; SNI IEC 62368-1:2014; SNI 04-6253; IEC 62368-1; IEC 60950-1; IEC 60065; or relevant SNI or IEC standards, for SRD other than audio, video and information and communication technology (ICT).
- Non-Ionizing Radiation: Controls device radiation levels to keep them safe for users and the environment.
Automotive Radar Certification Process in Indonesia
For automotive radar devices to be used legally in Indonesia, certification from DJID is required. Here are the steps to get it:
Pre-testing the device
Before official testing, the device must be pre-tested first using measuring equipment such as a spectrum analyzer.
This helps ensure devices meet technical standards before being tested in authorized laboratories.
Testing at an official laboratory
After passing the pre-testing, the gadget will be sent to an assigned official research facility to experience testing according to the guidelines stipulated in the Ministerial Decree of the Ministry of Communication and Digital No. 260 of 2024.
Issuance of certificates
After the device passes testing, an official certificate will be issued by DJID. This certificate is a requirement to market the device legally in Indonesia.
Tips to ensure standards compliance
- Learn the latest regulations: Make sure you understand every detail of the Ministerial Decree of the Ministry of Communication and Digital No. 260 of 2024, including technical requirements and test methods.
- Perform pre-testing: Before official testing, perform pre-testing to ensure the device meets standards. If you don’t have a measuring instrument, use the DJID certification service which provides pre-testing services.
- Counsel a master: If this is your to begin with time looking for certification, consider utilizing the administrations of experienced DJID certification administrations.
